角接觸球軸承, 精密, S .. CD, sealed, contact angle 15° | |||||||||||
公差 , see also text / text 718 (SEA) series | |||||||||||
預壓, see specific product, see also text, unmounted, and text, mounted / text 718 (SEA) series | |||||||||||
Recommended fits, shafts, housings | |||||||||||
軸和軸承座公差 | |||||||||||
![]() |
|||||||||||
主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
動態 | 靜態 | 當潤滑與 | SKF | SNFA | |||||||
油脂 | 滴油潤滑 | Listing of both SKF and SNFA designations means that | |||||||||
d | D | B | C | C0 | Pu | ||||||
![]() |
|||||||||||
mm | kN | kN | r/min | kg | - | ||||||
![]() |
|||||||||||
150 | 225 | 35 | 172 | 190 | 5,85 | 6000 | - | 4,15 | S7030 CD/P4A | - |
